Austro Engine E4 Series User Manual

E4 Series
Maintenance Manual
Power Plant
E4.08.04
Rev. 29
Page 7
71 - System Description
01-Jul-2020
Wiring Harness E4A-95-000-000 and E4B-95-000-000 Plug Connectors Description
Wiring
diagram
Description long version
German description
FPS
Fuel Pressure Sensor
Kraftstoffdrucksensor
RPS
Rail Pressure Sensor
Raildrucksensor
MOK
Oil Combinant Sensor
Temperature/ Oil Level
Kombinierter Ölsensor
Temperatur/ Ölstand
BPS1
Boost Pressure Sensor 1
Ladedrucksensor
BPS2
Boost Pressure Sensor 2
Ladedrucksensor
OPS
Oil Pressure Sensor
Öldrucksensor
IAT 1
Intake Air Temperature 1
Ladelufttemperatursensor
IAT 2
Intake Air Temperature 2
Ladelufttemperatursensor
CTS
Coolant Temperature Sensor
Kühlwassertemperatur
GBTS
Gearbox Temperatur Sensor
Getriebetemperatursensor
CTS_GPC
GPC Coolant Temperature
Kühlwassertemperatursensor GPC
FTS
Fuel Temperature Sensor
Kraftstofftemperatursensor
CAS 1
Camshaft Sensor 1
Nockenwellensensor
X)
CAS 2
Camshaft Sensor 2
Nockenwellensensor
X)
ECU A
ECU A
ECU A Stecker
ECU PWR
ECU Power
ECU Power Stecker
ECU B
ECU B
ECU B Stecker
GEN
Alternator Plug
Alternator Stecker
GPC
GPC Connector
GPC Stecker
CRS 1
Crankshaft Sensor 1
Kurbelwellensensor 1
CRS 2
Crankshaft Sensor 2
Kurbelwellensensor 2
GOV
Governor Actuator
Governor
GPC
Glow Plug Control
GPC Glow Plug Control
GP 1
Glow Plug 1
Glühkerze 1
GP 2
Glow Plug 2
Glühkerze 2
GP 3
Glow Plug 3
Glühkerze 3
GP 4
Glow Plug 4
Glühkerze 4
W11 / 1
Ground Connection GPC
Masse Verbindung für GPC
W11 / 2
Ground Connection Governor
Masse Verbindung für Governor
X1/1
CPC 1 A/C Interface 1
CPC 1 Zellenanbindung
X1/2
CPC 2 A/C Interface 2
CPC 2 Zellenanbindung
BPA
Boost Pressure Actuator
Ladedrucksteller
Elektrisch Pneumatischer Wandler
(EPW)
PCV
Pressure Control Valve
Druckregelventil High Pressure Rail
INJ 1
Fuel Injector 1
Kraftstoff Injektor 1
X)
INJ 2
Fuel Injector 2
Kraftstoff Injektor 2
X)
INJ 3
Fuel Injector 3
Injektor Kraftstoff Injektor 3
X)
