E4 Series

Maintenance Manual

Power Plant

Page 8

E4.08.04

Rev. 29

71 – System Description

01-Jul-2020

Wiring

diagram

Description long version

German description

INJ 4

Fuel Injector 4

Kraftstoff Injektor 4

FMU

Fuel Metering Unit

Zumesseinheit

X) Do a sensor check every 300 h, only if the Injector cover is removed.
