E4 Series
Maintenance Manual
Power Plant
E4.08.04
Rev. 29
Page 263
71 -Maintenance Procedures
01-Jul-2020
Detail Steps/Work Items
Key Items/References
Only the cable tie is permitted for connector adapter (of BPA filter)
attachment.
Do not tighten the BPA hose with too much force!
(7)
Attach the BPA filter.
Use a cable tie No.[05]
Fig. 71 - 82 BPA blade terminal installation
BPA
Blade Terminal [11] and washer for BPA
