E4 Series
Maintenance Manual
Power Plant
Page 286
E4.08.04
Rev. 29
71 - Maintenance Procedures
01-Jul-2020
Repair kit pin configuration
BPS1
1
ECUA
g
BPS1
2
ECUA
f
BPS1
3
ECUA
e
BPS2
1
ECUB
g
BPS2
2
ECUB
f
BPS2
3
ECUB
e
E4A-95-R19-000
Connector
Pin
Connector
Pin
CRS1
1
ECUA
W
CRS1
2
ECUA
X
CRS2
1
ECUB
W
CRS2
2
ECUB
X
E4A-95-R20-000
Connector
Pin
Connector
Pin
BPA
1
ECUPWR
M
BPA
2
ECUPWR
a
E4A-95-R21-000
Connector
Pin
Connector
Pin
INJ1
1
ECUPWR
Z
INJ1
2
ECUPWR
f
INJ2
1
ECUPWR
F
INJ2
2
ECUPWR
X
INJ3
1
ECUPWR
G
INJ3
2
ECUPWR
H
INJ4
1
ECUPWR
L
INJ4
2
ECUPWR
Y
Table 71 - 4
