E4 Series
Maintenance Manual
Power Plant
E4.08.04
Rev. 29
Page 295
71 -Maintenance Procedures
01-Jul-2020
Detail Steps/Work Items
Key Items/References
(2)
Remove the black and white cable
insulation.
(3)
Remove the shielding.
(4)
Put the solder sleeve over the engine
harness cable and above the shielding.
Apply heat to the solder sleeve until it
connects with the cable and the
shielding.
Use a hot air gun (300°C – 350°C).
50 mm (±5)
10 mm (+5 mm)
Solder Sleeve
