E4 Series
Maintenance Manual
Engine Oil
System
E4.08.04
Rev. 29
Page 227
79-Maintenance Procedures
01-Jul-2020
Detail Steps/Work Items
Key Items/References
(10)
Tighten the banjo bolt at the oil sump.
Torque 50 Nm.
(11)
Secure the banjo bolt at the oil sump with lock-
wire only after the ground run is completed.
Refer to Fig. 79 - 22.
(12)
Tighten the screw at the crankcase clamp.
Torque 21 Nm.
(13)
Clean the working area.
(14)
Refill the engine oil.
Refer to Section 79-20-00
Paragraph 5.B.
(15)
Do an engine ground run.
Refer to Section 71-00-01.
Make sure that the engine is cooled down.
(16)
Examine the oil system for leakage.
(17)
Tighten the banjo bolt again.
Torque 50 Nm.
(18)
Secure the banjo bolt with lock-wire only after
the ground run is completed.
Refer to Fig. 79 - 22.
