Austro Engine E4 Series

To Next Page

To Previous Page

E4 Series

Maintenance Manual

Engine Oil

System

Page 228

E4.08.04

Rev. 29

79-Maintenance Procedures

01-Jul-2020

Fig. 79 - 21 Oil return line gasket installation

O-Ring

Sealing

rings

gasket

Banjo bolt / adapter assembly

Refer to Paragraph C and D.

oil return line

Screws

Screw

clamp

Banjo bolt
