Austro Engine E4 Series

To Next Page

To Previous Page

E4 Series

Maintenance Manual

Turbocharging

E4.08.04

Rev. 29

Page 205

81- Maintenance Procedures

01-Jul-2020

Detail Steps/Work Items

Key Items/References

(9)

Do an engine ground run.

Refer to Section 71-00-01.

Fig. 81 - 8 BPA Configuration 1

BPA

Screws

Cylinder head cover

Bracket
