E4 Series

Maintenance Manual

Turbocharging

Page 206

E4.08.04

Rev. 29

81- Maintenance Procedures

01-Jul-2020

Fig. 81 - 9 Latest BPA installation version

Screw

Spacer

Clamp

BPA

Clamp

el. connector “BPA”

Clamp

Restrictor
