E4 Series
Maintenance Manual
Turbocharging
E4.08.04
Rev. 29
Page 215
81- Maintenance Procedures
01-Jul-2020
Detail Steps/Work Items
Key Items/References
(6)
Remove the clamp and disconnect the hose of the air
pressure device.
(7)
Connect the air hose to the wastegate controller again
and attach a new clamp.
Refer to Fig. 81 - 20.
Fig. 81 - 20 Wastegate Controller adjustment
Hose
Wastegate
controllerer
Clamp
