E4 Series
Maintenance Manual
Reciprocating
Engine
E4.08.04
Rev. 29
Page 237
85-Maintenance Procedures
01-Jul-2020
Fig. 85 - 51 Wear of the inner rivet head
Wear due to interference
requires additional
measurement.
min. 1,5mm
Fig. 85 - 52 Measurement of the worn rivet head
