E4 Series
Maintenance Manual
Reciprocating
Engine
E4.08.04
Rev. 29
Page 255
85-Maintenance Procedures
01-Jul-2020
a. Engine carrier mounting RH side
The installation of a threaded insert for a damaged thread is only permitted for the
threads shown in the following figure.
Fig. 85 - 75 Gearbox engine carrier mounting RH side
Fig. 85 - 76 Typical threaded insert (section view)
POS.1
POS.3
POS.2
POS.4
Threaded insert
