Datalogic Magellan 3450VSi User Manual

USB Keyboard Features Enter/Exit Programming Mode
Product Reference Guide 95
USB Keyboard Intercharacter Delay
Specifies a time delay between characters.
To set this feature:
1. Scan the Set USB Keyboard In
tercharacter Delay bar code below.
2. Scan the appropriate characters/digits from the Alpha-Numeric Keypad in
Appendix C that represent the desired delay. Th
e selectable range for this
option is any decimal value from 00 (no delay) to 99 in 10 ms increments.
A
table containing the ASCII Character Set and their corresponding decimal
values is available in the inside back cover of this manual. ASCII parame-
ters must be input by scanning decimal digi
ts for each character. Pad all
single digit numbers with leading zero to yield a two-digit entry (00-99).
Thus, to set an intercharacter delay of 70ms, bar codes containing the
digits ‘0’ and ‘7’ must be scanned.
3. Complete the programming sequence by
scanning the Enter/Exit Pro-
gramming Mode bar code.
0287(CR)
Set USB Keyboard Intercharacter Delay
DEFAULT
Default setting for this feature is: 01 (10ms)

Datalogic Magellan 3450VSi Specifications

General

Standard interfaces	RS-232
Connectivity technology	Wired
Type	Fixed bar code reader
Sensor type	LED
Scanner type	1D/2D
Read rate (max)	39000000 reads/s
Yaw reading angle	-75 - 75 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 86000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Input voltage	100-240 V
Input frequency	50-60 Hz
Power source type	AC
Power consumption (standby)	2.6 W
Power consumption (typical)	3 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP52
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	94 mm
Width	152 mm
Height	137 mm
Weight	600 g
