Datalogic Magellan 3450VSi User Manual

Standard 2 of 5 Length 1 Enter/Exit Programming Mode
Product Reference Guide 253
Standard 2 of 5 Length 1
If Standard 2 of 5 Length Control is set to Fixed-Length decoding, this feature
specifies Standard 2 of 5 first fixed length. If Standard 2of 5 Length Control is
set to Variable-Length decoding, this feature specifies the minimum label
length.
To set this feature:
1. Scan the ENTER/EXIT Prog
ramming Mode bar code.
2. Scan the bar code, Set Standard 2 of 5 Length 1 on page 253 below. You’ll
need to cover any unused bar codes on this and the facing page to ensure
that t
he scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Alpha-Numeric Keypa
d in Appendix C
that represent the desired l
abel length. The selectable range for this
option is 1 to 50. Pad all single digit numbers with a leading zero to yield a
two-digit entry (01-50).
4. Complete the programming sequence
by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
0498(CR)
Set Standard 2 of 5 Length 1
DEFAULT
Default setting for this feature = 08

Datalogic Magellan 3450VSi Specifications

General

Standard interfaces	RS-232
Connectivity technology	Wired
Type	Fixed bar code reader
Sensor type	LED
Scanner type	1D/2D
Read rate (max)	39000000 reads/s
Yaw reading angle	-75 - 75 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 86000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Input voltage	100-240 V
Input frequency	50-60 Hz
Power source type	AC
Power consumption (standby)	2.6 W
Power consumption (typical)	3 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP52
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	94 mm
Width	152 mm
Height	137 mm
Weight	600 g
