Enter/Exit Programming Mode QR Code Length Control
272
Magellan™ 3450VSi
QR Code Length 1, Length 2 Programming Instructions
If QR Code Length Control is set to Fixed-Length decoding, this feature speci-
fies QR Code first fixed length. If QR Cod
e Length Control is set to Variable-
Length decoding, this feature specifies the minimum label length.
NOTE
Length 1 is the minimum label len
gth if in variable length
mode, or the first fixed length if in fixed length mode. Length 2
is the maximum label length if in variable length mode, or the
second fixed length if in fixed length mode. Length includes
the bar code's data characters only. Any value > 2710 will be
considered to be 2710.
To set this feature:
1. Scan the ENTER/EXIT Prog
ramming Mode bar code.
2. Scan the bar code, Set QR Code Length 1 on page 272 or Set QR Code
Length 2 on page 272 below. You’ll need to cover any
unused bar codes
on this and the facing page to ensure that the scanner reads only the bar
co
de you intend to scan.
3. Scan the appropriate digits from the Alpha-Numeric Keypa
d in Appendix C
that represent the desired l
abel length. The selectable range for this
option is 0001 to 2710. Pad all numbers with leading zeros to yield a four-
digit entry (001-02710).
4. Complete the programming sequence
by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
Default setting for this feature = 0001
Set QR Code Length 1
Set QR Code Length 2
Default setting for this feature = 0A96
