Datalogic Magellan 3450VSi User Manual

EAN-8 Minimum Segment Length Enter/Exit Programming Mode
Product Reference Guide 141
EAN-8 Minimum Segment Length
Specifies the minimum number of characters necessary in an EAN-8/JAN-8 label
segment in order for the scanner to accept a label for decoding. Selectable from 5 to
15 characters. Default setting for this feature is: 08 (8 characters).
EAN-8 Minimum Segment Length = 5 characters
EAN-8 Minimum Segment Length = 6 characters
EAN-8 Minimum Segment Length = 7 characters
EAN-8 Minimum Segment Length = 8 characters
EAN-8 Minimum Segment Length = 9 characters
EAN-8 Minimum Segment Length = 10 characters
EAN-8 Minimum Segment Length = 11 characters
049D05(CR)
049D06(CR)
049D07(CR)
049D08(CR)
DEFAULT
049D09(CR)
049D0A(CR)
049D0B(CR)

Datalogic Magellan 3450VSi Specifications

General

Standard interfaces	RS-232
Connectivity technology	Wired
Type	Fixed bar code reader
Sensor type	LED
Scanner type	1D/2D
Read rate (max)	39000000 reads/s
Yaw reading angle	-75 - 75 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 86000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Input voltage	100-240 V
Input frequency	50-60 Hz
Power source type	AC
Power consumption (standby)	2.6 W
Power consumption (typical)	3 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP52
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	94 mm
Width	152 mm
Height	137 mm
Weight	600 g
