RS-232 Interface Features Enter/Exit Programming Mode
Product Reference Guide
73
RS-232 ACK NAK Timeout Value
This item specifies the time the scanner will wait for an ACK character from the
host following a label transmission.
•0 = Infinite timeout
• 1 - 75 = Timeout in 200-millisecond increments
To set the ACK NAK Timeout Value:
1. Scan the Enter/Exit Progr
amming Mode bar code.
2. Scan the bar code below, Set RS-2
32 ACK NAK Timeout Value. You’ll need
to cover any unused bar codes on this and the facing page to ensure that
the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the Alpha-Numeric Keypad in Appendix C
that represent the desired timeout. A sett
ing of 0 specifies an infinite tim-
eout. The remaining selectable range is 1-75, which is the timeout in 200-
mi
llisecond increments. Pad all single digit numbers with a leading zero to
yield a two-digit entry (00-75).
Examples:
00 = Infinite timeout
01 = 200ms
05 = 1,000ms (1 second)
40 = 8,000ms (8 seconds)
75 = 15,000ms (15 seconds)
The scanner will automatically exit Programming Mode when the appropriate
am
ount of digits have been scanned.
Set RS-232 ACK NAK Timeout Value
DEFAULT
Default setting for this feature is:
01 - 200ms
To Next Page
