Enter/Exit Programming Mode Data Matrix Length Control
260
Magellan™ 3450VSi
Data Matrix Length 1, Length 2 Programming Instructions
If Data Matrix Length Control is set to Fixed-Length decoding, this feature
specifies Data Matrix first fixed length. If Data Matrix Length Control is set to
Variable-Length decoding, this feature specifies the minimum label length.
NOTE
For Data Matrix bar codes, only the data characters are
inc
luded in the length calculations.
To set this feature:
1. Scan the ENTER/EXIT Prog
ramming Mode bar code.
2. Scan the bar code, Set Data Matrix Length 1 on page 260or Set Data Matrix
Length 2 on page 260 below. You’ll need to cover any
unused bar codes
on this and the facing page to ensure that the scanner reads only the bar
co
de you intend to scan.
3. Scan the appropriate digits from the Alpha-Numeric Keypa
d in Appendix C
that represent the desired l
abel length. The selectable range for this
option is 0001 to 3116. Pad all numbers with leading zeros to yield a four-
digit entry (0001-3116).
4. Complete the programming sequence
by scanning the ENTER/EXIT Pro-
gramming Mode bar code.
Default setting for this feature = 0001
Set Data Matrix Length 1
Set Data Matrix Length 2
Default setting for this feature = 0320
