Reading Performance
288 Magellan™ 3450VSi
Reading Performance
Parameter Specification
Image Capture Graphic Formats: BMP, JPEG
Imager Sensor 1280 X 1024
Light Source
Multiple Diffused LEDS, Orientation and Wavelength Optimized
for Eye Comf
ort
Print Contrast Ratio (Minimum) 25%
Read Height 14.0 cm / 5.5 in
Read Rate (Maximum) 39 Million Pixels per Second
Reading Angle
Pitch: +/- 65°; Roll (Tilt): 0 - 360°;
Skew (Yaw): +/- 75°
Reading Indicators
Audio Speaker w/Adjustable Tone and Volume,
Supports .wav Files; Good Read LED; Good Transmission
Resolution (Maximum) 5 Mil
Reading Ranges
Parameter Specification
Typical Depth Of Field
Printing Resolution, Symbol Length, Scan A
ngle, Contrast and
Ambient Light Dependent
1D / Linear Codes
5 Mils: 3.8 to 8.1 cm / 1.5 to 3.2 in
7.5 Mils: 1.3 to 11.4 cm / 0.5 to 4.5 in
10 Mils: 0 to 15.2 cm / 0 to 6.0 in
13 Mils: 0 to 20.3 cm / 0 to 8.0 in
2D Codes (Optional)
6.6 Mils: PDF: 3.8 to 10.2 cm / 1.5 to 4.0 in
10 Mils: PDF: 0 to 12.7 cm / 0 to 5.0 in
10 Mils: Data Matrix: 1.3 to 6.4 cm / 0.5 to 2.5 in
20 Mils: Data Matrix: 0 to 18.0 cm / 0 to 7.0 in
Safety & Regulatory
Parameter Specification
Agency Approvals
The product meets necessary safety and regulatory approvals for
its intended use.
Environmental Compliance Complies to China RoHS; Complies to EU RoHS
LED Classification EN62471 and IEC62471 Lamp Illumination - Exempt Group

Datalogic Magellan 3450VSi Specifications

General

Standard interfaces	RS-232
Connectivity technology	Wired
Type	Fixed bar code reader
Sensor type	LED
Scanner type	1D/2D
Read rate (max)	39000000 reads/s
Yaw reading angle	-75 - 75 °
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 86000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, QR Code
Input voltage	100-240 V
Input frequency	50-60 Hz
Power source type	AC
Power consumption (standby)	2.6 W
Power consumption (typical)	3 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
International Protection (IP) code	IP52
Sustainability certificates	RoHS
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	94 mm
Width	152 mm
Height	137 mm
Weight	600 g
