When USTRS (User Transition) is selected for TYPE:
Setting Function Button Indication
KEY1-4 SCALER
Performs the user transition for keys.
On-Air: Lit orange,
Off-Air: Unlit
KEY1-4 MIX
KEY1-4 SLIDE LEFT
KEY1-4 SLIDE RIGHT
KEY1-4 SLIDE TOP
KEY1-4 SLIDE BOTTOM
KEY1-4 WIPE LEFT
KEY1-4 WIPE RIGHT
KEY1-4 WIPE TOP
KEY1-4 WIPE BOTTOM
When KEYER is selected for TYPE:
Setting Function Button Indication
KEY1-4 2D DVE ENABLE Sets 2D DVE On/Off.
ON: Lit orange,
OFF: Unlit
KEY1-4 BOX MASK AND ENABLE Sets AND type BOX MASK On/Off.
KEY1-4 BOX MASK OR ENABLE Sets OR type BOX MASK On/Off.
KEY1-2 EDGE NORMAL ENABLE Sets Normal Edge On/Off.
KEY1-2 EDGE OUTLINE ENABLE Sets Outline Edge On/Off.
KEY1-4 FIELD FREEZE ENABLE Sets Field Freeze On/Off.
KEY1-4 FRAME FREEZE ENABLE Sets Frame Freeze On/Off.
PREVIEW OUT-KEY1-4 Sets keys On or Off for preview outputs.
KEY1,2 / 3,4 PRIORITY Changes the key priority.
When VTR is selected for TYPE (planned for future support):
Setting Function Button Indication
VTR/VDCP REW
Operates the connected VTR or VDCP
channel.
During execution: Lit,
Other cases: Unlit
VTR/VDCP PLAY/PAUSE
VTR/VDCP FWD
VTR/VDCP STOP Always lit orange
VTR/VDCP REC
During execution: Lit,
Other cases: Unlit
VTR/VDCP STEP REV
Always lit orange
VTR/VDCP STEP FWD
VTR/VDCP CUE UP
VDCP MARK IN
VDCP MARK OUT
VDCP TC DISPLAY
Displays time code information when
controlling VDCP devices.
Always lit orange
VTR1-4 SELECT
Selects a VTR or VDCP channel for
control. Selecting the channel again
deselects it.
Channel selected:
Lit orange
Other cases: Unlit
VDCP1-4 SELECT
VTR1-4 REW Rewinds video on VTR1-4.
During execution: Lit,
Other cases: Unlit
VTR1-4 PLAY Plays video on VTR1-4.
VTR1-4 PAUSE Pauses video on VTR1-4. Always unlit
VTR1-4 FWD Fast-forwards video VTR1-4.
During execution: Lit,
Other cases: Unlit
VTR1-4 STOP Stops recoding/playback on VTR1-4. Always unlit
VTR1-4 REC Records video on VTR1-4.
During execution: Lit,
Other cases: Unlit
VTR1-4 GOTO TOP Cues to 00:00:00:00 on VTR1-4 Always unlit
VDCP1-4 REW Rewinds video on VDCP1-4.
During execution: Lit,
Other cases: Unlit
VDCP1-4 PLAY Plays video on VDCP1-4.
