4 Fax
150
Fax
4
Note • There are two methods in the DTMF method: Auto Send and Manual Send.
• This method is only available for transmission between machines of this model.
The dialing format can be registered in address number to enable dialing using an address
number. For information on how to register address numbers, refer to "Address Book
(Address Number)" (P.347).
*When the Speed Dial Extension Kit is installed, it will be 001 to 999.
Auto Send (transmitting without picking up the telephone)
1 Select [Keyboard] to display the keyboard on the touch screen and enter the following
format.
2 Select [Next Recipient] to perform Multiple Relay Broadcast.
îš„Password
A pre-registered two-digit number
Note • By default, no password is set. For setting a password, contact our Customer Support
Center. If a password has not been set, you do not need to enter one.
îš„Relay station ID
The last two digits of the initiating station address number registered at the primary
relay station.
îš„Address number
The address number for the secondary relay station registered at the primary relay
station.
Manual Send (transmitting with picking up the telephone or on-hook)
1 Display the [On-hook/Others]
screen by selecting the [On-hook/
Others] tab.
2 Select [On-hook (Manual Send/
Receive)].
3 Select [Manual Send].
4 Select [Alphanumeric] or [Symbol].
5 Use the keyboard shown in the touch screen to enter the following format.
Note • You can specify up to 20 locations for relay recipients.
Secondary
relay
station
Assign the primary relay station to the same address number as that of the
initiating station registered at the primary relay station, and set Relay Station
Setup of the address number to [On].
Assign the relay recipient to an address number from 001 to 500
*
.
Where Contents
Address
number
Address
number
To Next Page
