îš„Print Command
Existence of printing at the relay station
1: Printing at the relay station
0: No printing at the relay station
îš„Relay Station ID
An address number for an initiating station registered at the relay station.
When the relay station ID is set, the initiating station is notified of the results of a Relay
Broadcast Send.
When the relay station ID is "00" or "000", the initiating station is not notified of the
results of a Relay Broadcast Send.
îš„Address Number
The address number assigned to the relay recipient.
The following shows an example of F Code that indicates printing at the relay station,
notifying the initiating station (100) of the results, and performing Relay Broadcast
Send to relay recipients (200, 201, 202 and 203).
F Code Example: 21100200201202203
1 Display the [Send Options] screen
by selecting the [Send Options]
tab.
2 Select [F Code] on the [Send
Options] screen.
3 Select [On].
4 Enter the F Code with the numeric keypad and select [Next].
You can enter up to 20 digits for the F Code.
5 If necessary, enter the password using the numeric keypad and select [Next].
You can enter up to 20 digits for the password.
Remote Relay Broadcast
(Performing Relay Broadcast to Remote Locations)
The Remote Relay Broadcast feature combines two or more Relay Broadcast
operations.
This feature is more economical than Relay Broadcast in transmitting documents to
multiple remote machines.
Note • Multiple Relay Broadcast can be performed from a secondary relay station.
• For information on which models of machines can be used as Remote Relay Broadcast
secondary relay stations and primary relay stations, refer to "Models Available for Relay
Broadcast Send" (P.152).
There are three Relay Broadcast Send methods.
îš„Fax Signal Method
This method employs a Fuji Xerox proprietary communication procedure that is only for
use with specific machines that have the Relay Broadcast Send feature. The G3 mode
is available.
To Next Page
