11 System Settings
354
System Settings
11
S/MIME Certificate
Makes a link with S/MINE certificate. A S/MINE certificate needs to be registered in
advance.
In order to link a certificate, select a certificate in a screen displayed when selecting
[Create/Change Link]. To delete a link, select [Cut Link].
For information on the certificate, refer to the Network Administrator Guide.
Transfer Protocol
Set the forwarding destination protocol. You can select from [FTP] and [SMB].
Server Name/IP address
Enter a name or IP address of a forwarding destination server.
Shared Name (SMB Only)
Enter the shared name set for the SMB folder.
Important • If the “/” mark is used at the top of a shared name, a job flow cannot read the shared name
correctly. Do not use the “/” mark at the top of a shared name.
Save In
Enter the directory for storing documents. When SMB is selected, use a UNC format.
z
Forwarding via FTP
Example: To save in the bbb directory under the aaa directory in the root directory.
aaa/bbb
z
Forwarding via SMB
Example: To save in the bbb directory under the aaa directory in a specified volume
(UNC format).
aaa\bbb
Login Name
When a login name is required to be input by the forwarding destination server, set the
login name. For the login name, you can enter up to 32 characters.
Password
When a password is required to be input by the forwarding destination server, set the
password. You can enter a password up to 32 characters.
Port Number
Set the forwarding destination port number. Input a number in the range 1 to 65535.
Delete All Settings
Deletes all registered information for the selected address. To delete all registered
information, select [Yes].
Important • Deleted information cannot be recovered.
