Control Panel
41
Product Overview
2
10 <Clear All> button Returns the statuses of all displayed services to their default values.
The machine will be reset to this state after it is turned on.
In this manual, this button is indicated as the <Clear All> button.
11 <Interrupt> button/indicator Press this button to temporarily stop a continuous copy job or printing to
give another job higher priority. During an interrupt, the interrupt
indicator lights up. Pressing the <Interrupt> button again cancels the
interrupt and the previous operation is resumed.
In this manual, this button is indicated as the <Interrupt> button.
Some jobs such as print jobs designated from client computers cannot be
executed during the interruption. For detail information, refer to "Notes and
Restrictions on the Use of Interruption Feature" under "Chapter 17 Appendix"
in the User Guide.
12 <Stop> button Press this button to stop the current copy job or communications.
In this manual, this button is indicated as the <Stop> button.
13 <Start> button Press this button to start copying or scanning.
In this manual, this button is indicated as the <Start> button.
14 Numeric keypad Press these buttons to enter the number of copies, passwords and other
numerical values.
In this manual, these buttons are indicated as the “numeric keypad”.
15 <Speed Dial> button Used to specify a destination phone number for fax or e-mail.
In this manual, this button is indicated as the <Speed Dial> button.
16 <C (Clear)> button Press this button if you have entered the wrong numerical value with the
numeric keypad.
In this manual, this button is indicated as the <C> button.
17 <Dial Pause> button Used to insert a pause into a destination number.
In this manual, this button is indicated as the <Dial Pause> button.
18 <Custom> buttons
(<Copy>, <Custom 2>,
<Custom 3> buttons)
Used to call a custom feature.
You can assign a feature to the buttons selected from the features
displayed on the [All Services] screen and [Language].
In this manual, these buttons are indicated as the <Copy>, <Custom 2>
and <Custom 3> buttons.
For information on registering a feature with a button, refer to "Screen
Defaults" under "Chapter 11 Setups" in the User Guide.
19
<All Services> button
Used to display the [All Services] screen.
In this manual, this butto
n is indicated as the <All Service
s> button.
You can change the features that appear in the <All Services> screen. For detail
information, refer to "Screen Defaults" in "Chapter 11 Setups" in the User
Guide.
20 One touch button panels Panels for one touch buttons.
You can leaf through panels to display 001 to 030, 031 to 060, and 061
to 070. M01 to M20 are reserved for job memory. These buttons
correspond to jobs registered in 01 to 20.
21 One touch buttons Specify a recipient with one button. These buttons are available for the
fax, iFax, and E-mail features.
Registered preset recipient numbers 001 to 070 are supported.
No. Component Function
