Removing a 3.5-inch HDD dummy module
Unusable HDD bays contain a HDD dummy with dummy lock to prevent
customer from erroneously adding a HDD.
Figure 58: Removing the dummy lock
▶
Pull the dummy lock out of the dummy cover. Please be aware that the
dummy lock can be damaged.
Figure 59: Removing the 3.5-inch dummy module
▶
Press both tabs together (1) and pull the dummy module out of its bay (2).
CAUTION
▶
Keep the dummy module for future use.
▶
Always replace dummy modules into unused HDD/SSD bays to
comply with applicable EMC regulations and satisfy cooling
requirements.
Hard disk drive (HDD) / solid state disk (SSD)
146 Upgrade and Maintenance Manual RX2540 M6
