Only valid after upgrading the server with the second HDD backplane: pull
the dummy lock out of the dummy cover. Please be aware that the dummy
lock can be damaged.
Removing a 2.5-inch HDD/SSD dummy module
Figure 80: Removing a 2.5-inch HDD/SSD dummy module
â–¶
Press both tabs together (1) and pull the dummy module out of its bay
(2).
CAUTION
â–¶
Keep the dummy module for future use.
â–¶
Always replace dummy modules into unused HDD/SSD bays to
comply with applicable EMC regulations and satisfy cooling
requirements.
Installing a 2.5-inch PCIe SSD module
Figure 81: Opening the locking lever
Hard disk drive (HDD) / solid state disk (SSD)
174 Upgrade and Maintenance Manual RX2540 M6
