Figure 87: Connecting cables to the 8x 2.5-inch HDD backplane (example onboard SATA)
▶
Connect the following cables to the HDD backplane:
1 SAS/SATA cable
2 Power cable
3 SAS/SATA cable
4 OOB cable
For the cable plan, see "Appendix B" on page 571
.
Example combo HDD backplane:
Hard disk drive (HDD) / solid state disk (SSD)
182 Upgrade and Maintenance Manual RX2540 M6
