Fujitsu PRIMERGY RX2540 M6

1 Signal cable
2 Power cable
3 Slimline cable
4 Slimline cable
5 Power cable
6 Power cable
7 Slimline cable
8 Slimline cable
For the cable plan, see "Appendix B" on page 571.
Concluding steps
▶
"Installing the fan cage" on page 76
.
▶
"Reassembling" on page 60.
▶
Insert all PCIe SSD modules, see "Installing a 2.5-inch HDD/SSD module"
on page 167.
Ensure that you install the PCIe SSD module in the bay it was located
before the HDD backplane replacement.
▶
Insert all dummy modules, see "Installing the 2.5-inch HDD/SSD dummy
module" on page
170
.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M6 Upgrade and Maintenance Manual 187
