Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 87
.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
Removing the expansion card
▶
If applicable, disconnect internal cables from the expansion card.
▶
If applicable, "Removing an SFP+ transceiver module" on page 246.
Figure 158: Removing the expansion card
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 263
