Fujitsu PRIMERGY RX2540 M6

Figure 225: Installing the CPU frame on the CPU
▶
Click the CPU frame into the CPU. Ensure that the triangle marks on CPU
and on CPU frame are on the same edge (see circles).
▶
Ensure that the CPU fits in its place.
Processor (CPU)
RX2540 M6 Upgrade and Maintenance Manual 351
