Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Installing the heat sink
Figure 226: Marks on heat sink and CPU frame
▶
If applicable, remove the protective cover from the heat sink.
▶
If using a heat sink again, clean residual thermal paste from the heat sink
surface using a lint-free cloth.
▶
Ensure that the triangle marks on the heat sink and on CPU frame are on
the same edge (see circles).
Processor (CPU)
352 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
