Fujitsu PRIMERGY RX2540 M6

Figure 300: Installing the rails to the RDX drive (B)
▶
Ensure that the rails are in alignment with the RDX drive (see line).
Installing an RDX drive
Figure 301: Installing the RDX drive (A)
Accessible drives
434 Upgrade and Maintenance Manual RX2540 M6
