Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
–
Torx 30 screw driver
Replacing the TPM:
– Bit screw driver
–
TPM bit insert
(*)
– flat nose pliers
–
thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
CAUTION
▶
Advise your contact persons that they must provide you with all
recovery keys which belong to the system to restore them in the
TPM later.
Preliminary steps
▶
"Locating the defective server" on page 49.
▶
"Suspending BitLocker functionality" on page
87.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
Remove all PSUs, see "Removing a hot-plug PSU" on page 127.
▶
If applicable, remove the OCP module, see "Removing an OCP module" on
page 252.
▶
"Getting access to the component" on page 56.
▶
Remove all riser modules, see "Removing a riser module" on page 70.
System board and components
RX2540 M6 Upgrade and Maintenance Manual 489

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
