Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

▶
"Shutting down the server" on page 52
.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
If applicable, remove the expansion card from slot 5 and slot 6, see
"Removing an expansion card" on page 262.
Replacing the iRMC microSD card
▶
Remove the defective iRMC microSD card, see "Removing the iRMC
microSD card" on page 493.
CAUTION
(not valid for Europe, Middle East, India and Africa)
The iRMC microSD card contains customer information.
▶
After removing the iRMC microSD card, hand the card over to
the customer.
▶
If the customer requests disposal of the defective microSD card,
proceed as follows: Using a pair of side-cutting pliers, cut the
microSD card in half.
▶
Install the new iRMC microSD card, see "Installing the iRMC microSD card"
on page 491.
Concluding steps
▶
If applicable, install the expansion card in slot 5 and 6, see "Installing an
expansion card" on page
255
.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
Update the BIOS or iRMC S5 firmware using the iRMC S5 web interface,
see "Updating the BIOS or iRMC S5 firmware using the iRMC S5 web
interface" on page 496.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
System board and components
RX2540 M6 Upgrade and Maintenance Manual 495

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
