Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 52
.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
If applicable, "Removing the riser module 1" on page 70.
Installing the Dual microSD 64GB Enterprise
Figure 353: Connecting the cable to the Dual microSD 64GB Enterprise
▶
Connect the cable to connector "CON2" on the Dual microSD 64GB
Enterprise.
System board and components
506 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
