Figure 386: Quick connectors for liquid cooling
1 Quick connector with red marking:
water outlet
2 Quick connector with blue marking:
water inlet
17.2.3.2 ID, CSS and Global Error indicators
Figure 387: ID, CSS and Global Error indicators
1 ID indicator
2 CSS indicator
3
Global Error indicator
ID indicator (1)
See also "iRMC-related status signals" on page 562.
Appendix A
560 Upgrade and Maintenance Manual RX2540 M6
