GRASS VALLEY MASTERPIECE User Manual

108
Engineering, User & Panel Configuration
Input Setup
The “Timing” parameter indicates the Offset in Micro seconds (or Milli Seconds) between the
Reference input and the selected source. To Clean switch or avoid a Line offset (e.g. a vertical
shift) the Timing has to be within +/- half a line of the current standard. e.g. for
1920x1080i59.94 +/-14uS).
To Adjust this timing window go to the “Eng Config/System Standard” menu and adjust the
Genlock phase. NB adjustment of the Gen Lock Phase will also adjust the Video Outputs to have
a Phase offset from the incoming reference. The Output Offset is +2 Lines from the Reference +
Genlock Phase.
The CRC (Cyclic Redundancy Check) field shows the CRC for the current Frame. e.g. In general
this will be a changing number for a moving picture and a static number for a still.
Note: All Sources have to be within this window. Any sources outside this
window can be corrected by using FormatFusion.
