133
Masterpiece
User Manual
YUV
Touch the {YUV} button to enable the parameter controls. Touch the YUV Control attacher
and by changing the parameters, the Brightness, Contrast and Saturation of the channel can be
adjusted.
• Brightness default value is 0.00%, and the range is from -10% to 100%
• Contrast default value is 1.00%, and the range is from -0% to 16%
• Saturation default value is 1.00%, and the range is from -0% to 16%
As each of the above are adjusted notice that the percentage of adjustment is shown in the
YUV attacher.
Bleed
Color bleed is a situation where a single color will over power the other colors in the RGB signal.
By using the bleed function the stronger color can be softened to make the color output more
natural, or adjusted to suit a specific need.
The initial menu has a default state where a single adjustment for each parameter menu is
active; this will allow the adjustment of the main RGB bleed parameters:
•Red into Red
• Green into Green
•Blue into Blue
Touch one of the Bleed color blocks to enable all the options for that color. This will allow a
detailed adjustment for each of the R, G and B bleed settings. The adjustments are measured
on a -100% to a +100% scale. Each parameter menu will adjust a single color, i.e. red into red,
green into red and blue into red. These changes are also reflected graphically in the RGB bar
graphs above the parameter sets.
