Honeywell SmartPAC 2 User Manual

SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 85
Cam output
board
Cam output
enclosure
XX.XX = inches
(XX.X) = mm
sockets for
standard relays
(channels 1
through 8)
terminals for connecting wires to equipment
clearance hole
for #6 screw
(4 places)
sockets for solid state relays
only (channels 5 through 8)
TB303
TB302
CHAN 1CHAN 2CHAN 3CHAN 4CHAN 5CHAN 6CHAN 7CHAN 8
DS301
TB301
6.00
(152.4)
5.50
(139.7)
NOTE:
For each channel, 5 - 8,
plug in standard or
solid state, but not both
CH1CH2CH3CH4CH5CH6CH7CH8
Connections to control
6.00
(152.4)
0.312 (7.9) dia.
4 places
8.00
(203.2)
10.00
(254.0)
3.50
(88.9)
10.75
(273.1)
Figure 2 - 22. ProCamPAC Output Assembly
