SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 89
c n/o
Power
in
Power
Return
RIGHT
Suppressor
ProCamPAC output relay
c n/o
Power
in
ACCEPTABLE
Suppressor
not prefered
Power
Return
Power
Return
c n/o
Power
in
WRONG
Suppressor
Power
Return
Load
Load
Load
ProCamPAC output relay
ProCamPAC output relay
Figure 2 - 25. How to Connect Suppressors Across the Load
