1126800 SmartPAC 2 with WPC Integration
Page 164 Chapter 2 Installing SmartPAC 2 and WPC
Cams 1-8
TB401 TB451
Cams 9-16
TB452
ProCamPAC 8 board ProCamPAC 16 board
Fuse
F401
Fuse
F451
Figure 2 - 41. ProCamPAC Boards, Location of Important Components
8-channel (left), 16-channel (right)
