SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 163
DiProPAC 8 board DiProPAC 16 board
Sensors 1-8
TB501
TB551
Sensors 9-16
TB552
LED s 1-8
LED s 9-16
Aux Out
TB500
Aux Out
TB550
Fuse
F501
Fuse
F551
Figure 2 - 40. DiProPAC Boards, Location of Components
8-channel (left), 16-channel (right)
