SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 167
Table 2 - 19. SmartPAC 2 Wiring: Input Check and Stop Circuits (TB102)
SmartPAC 2
TB102
Terminal
Wiring
Designation
WPC Control
Board
Pin #
205 A 41
206 B 29
207 E-Stop 68
208 E-Stop 67
209 Top Stop 80
210 Top Stop 79
Table 2 - 20. SmartPAC 2 Wiring: SFI Port (1) and Module Port (2) (TB103)
SmartPAC 2
TB103
Signal Port
235 +RXD1 SFI PORT (1)
236 –RXD1
237 TXD1
238 +TXD1
239 –TXD1
240 Grd
241 +RXD2 MODULE PORT (2)
242 –RXD2
243 +TXD2
244 –TXD2
