1126800 SmartPAC 2 with WPC Integration
Page 168 Chapter 2 Installing SmartPAC 2 and WPC
Table 2 - 21. SmartPAC 2 Wiring: Special Port (3) and PACNet Port (4) (TB104)
SmartPAC 2
TB104
Connections Port
224 +RXD3 SPECIAL PORT (3)
225 –RXD3 “
226 TXD3 “
227 +TXD3 “
228 –TXD3 “
229 Grd “
230 +RXD4 PACNET PORT (4)
231 –RXD4 “
232 TXD4 “
233 +TXD4 “
234 –TXD4 “
Table 2 - 22. SmartPAC 2 Wiring: Spare 1 Port (5) and WPC Port (6) (TB105)
SmartPAC 2
TB105
Pin #
Connections Port
330 –TXD6 WPC PORT (6)
329 +TXD6 “
328 –RXD6 “
327 +RXD6 “
326 Grd “
325 –TXD5 SPARE 1 PORT (5)
324 +TXD5 “
323 TXD5 “
322 –RXD5 “
321 +RXD5 “
To Next Page
