Honeywell SmartPAC 2 User Manual

SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 169
Table 2 - 23. SmartPAC 2 Wiring: Spare 3 Port (7) and Spare 4 Port (8)
(TB106)
SmartPAC 2
TB106
Pin #
Connections Port
320 –TXD8 SPARE 2 PORT (8)
319 +TXD8 “
318 TXD8 “
317 –RXD8 “
316 +RXD8 “
315 Grd “
314 –TXD7 SPARE 3 PORT (7)
313 +TXD7 “
312 TXD7 “
311 –RXD7 “
310 +RXD7 “
Table 2 - 24. SmartPAC 2 Wiring: Aux I/O (TB107)
SmartPAC 2
TB107
Pin #
Connections
245 +15 V
246 POSITION SENSOR
247 GRD
248 ZERO
249 REMOTE RESET
250 GRD
251 LOCKOUT
252 INCH/SETUP
253 OP STA 2
254 OP STA 1
