SmartPAC 2 with WPC Integration 1126800
Introduction to SmartPAC 2 Chapter 1 page 21
Specifications: SmartPAC 2 with WPC
Additional WPC
Inputs
Motor
Forward and reverse contacts
Shadow light curtains (2)
Checks proper functioning at every stroke initiation and stop
Customized Status Codes
Four for E-stop
Three for top stop
One pair cross-checked inputs for E-stop
One pair cross-checked inputs for E-stop/lockout
WPC Outputs
DSV
2 monitored relays; rating 4 A @ 120 VAC; for emergency and top stopping
Lockout
1 monitored relay, rating 4 A @ 120 VAC; for de-energizing motor and other devices
under critical conditions
Auxiliary Stop Output
Allows to stop auxiliary equipment during an interrupted stroke
SmartPAC 2
Options
DiProPAC* provides up to 16 die protection sensor inputs
Power for electronic sensors (NPN only): 12 VDC min, 100 mA total
Sensor inputs 1 through 4 and 9 through 12: Low impedance
Sensor inputs 5 through 8 and 13 through 16: High impedance
Optional sensor inputs for all 1-16: Low impedance (<1000 Ω)
DiPro Sensor Interface, DSI 2
1
: 5.88" x 5.41" x 3.42" (149 x 137 x 87 mm)
DiPro RCB: 4.56" x 2.56" x 4.06" (116 x 65 x 103 mm)
DiProPAC sensor-disabled output: open collector, 8 mA max.
SmartPAC 2
Options,
continued
ProCamPAC* provides up to 16 programmable cam switch output channels
Programmable cam output assembly (NEMA 12; holds up to 8 outputs)
Enclosure: 9" x 11" x 3.5" (229 x 279 x 89 mm) shock-mounted
Relay SPDT 0-4 A resistive @ 240V
DC solid state SPST 2A @ 5-60 VDC
AC solid state SPST 1A @ 70-250 VAC
SmartPAC 2
Options,
continued
AutoSetPAC* or WaveFormPAC* 10.25" x 12" x 4" (260 x 305 x 102 mm)
2 or 4 strain link inputs
Ability to store high, low, and repeatability setpoints with tool number
Display, adjust, recalculate "auto" setpoints and display actual load
Display and save load signatures
With WaveFormPAC: Up to 4 windows to monitor tonnage at points other than the
peak
SmartPAC 2
Options,
continued
SFI* ServoFeed Interface integrates servofeed
RamPAC* 10.25" x 12" x 4" (260 x 305 x 102 mm)
Automatically sets shut height and counterbalance and cushion pressures
SmartPAC 2
Options,
continued
ProPAC*
12.3" x 14" x 4.3" (312 x 356 x 109 mm)
Provides up to 16 analog, NPN or PNP inputs
Ability to store high, low, and repeatability setpoints with tool number
Display and adjust manual or auto setpoints and display actual values
Monitor in-die dimensions and other process parameters
