Action Yes No
Step 7
Replace the sensor. See
“Sensor (booklet maker fold exit) removal” on
page 515.
Does the problem remain?
Go to step 8. The problem is solved.
Step 8
a Make sure that the trifold diverter is properly installed.
b Check the diverter for damage, and replace if necessary. See “Trifold
diverter removal” on page 514.
Does the problem remain?
Go to step 9. The problem is solved.
Step 9
a Make sure that the bifold knife and sliders are properly installed.
b Check the knife and sliders for wear or damage. See “Bifold knife
removal” on page 521.
Does the problem remain?
Go to step 10. The problem is solved.
Step 10
a Remove the right cover.
b Test the motor (bifold knife).
Enter the Diagnostics menu, and then navigate to:
Motor Tests > Booklet Maker Motor Tests > Center fold knife
c Check if the knife and gears are properly moving.
Are they properly moving?
Go to step 12. Go to step 11.
Step 11
a Reseat the cable on the motor.
b Make sure that the motor is properly installed.
c Check the motor and cable for damage, and replace if necessary. See
“Motor (bifold knife) removal” on page 491.
Does the problem remain?
Go to step 12. The problem is solved.
Step 12
Check the bifold knife drive and idler gears for wear or damage, and
replace if necessary. See
“Booklet maker—Fold section 1” on page 609.
Does the problem remain?
Go to step 13. The problem is solved.
4021, 7421
Diagnostic information
84
