NTP-006: Operation 365-575-102
Page2of4 Issue8.0,July2002
Operation: NTP-006---+---DLP-501
+---DLP-524
Figure 1 – Five Node Ring with DRI Cross-Connections
5. From the STS-3 (or STS1) Tributary Map Report,
identify the source, destination, primary, and
secondary nodes by referring to Figure 1 and to
Exhibit1forSTS3ortoExhibit2forSTS1. The
exhibits contain an explanation to Figure 1. Figure 1
and Exhibit 1 or Exhibit 2 use tributary 1 and slot 1a
for examples and that Worcester-MA is the location
requesting the report.
—
6. Discontinue the login to the node. (To discontinue a
remote login, refer to DLP-524.)
—
7. This completes the procedure to identify the primary,
secondary, source, and destinations nodes of a DRI
circuit.
—
DO ITEMS BELOW IN ORDER LISTED . . . . . . . . FOR DETAILS, GO TO
Worchester-MA
Salem-MA
Holyoke-MA
Concord-MA
Chicopee-MA
FT-2000 Ring
1E
1
1A
1W
1E
1W
1A
1E
1W
1
tpa 847809/01
1
1
1
1A
1
To Next Page
