Craft Interface Terminal Usage

11-122 Issue 8.0 July 2002

Example 39 - PERFORMANCE-Retrieve-PM Threshold-STS1 11

Releases 7 and Later (User the PERFORMANCE category.)

The report shows the current performance-monitoring threshold crossing alert

(TCA) values for the STS-1 path. This report is not available at the repeater site.

/* STS-1 Path Performance Monitoring Threshold Value Report

===========================================================================

-------- STS-1 Path (B3)/FEBE --------

Address Bin BER CV-P/F ES-P/F SES-P/F UAS-P/F

===========================================================================

sts1-1e-1-1 QH -9 1000 25 10 10

Day -9 1000 250 10 10

sts1-1e-1-2 QH -9 1000 25 10 10

Day -9 1000 250 10 10

sts1-1e-1-3 QH -9 1000 25 10 10

Day -9 1000 250 10 10

sts1-1e-2-1 QH -9 1000 25 10 10

Day -9 1000 250 10 10

sts1-1e-2-2 QH -9 1000 25 10 10

Day -9 1000 250 10 10

.. . ....

sts1-1e-16-3 QH -9 1000 25 10 10

Day -9 1000 250 10 10

/* STS-1 Path TCA Autonomous Reporting Status Report

===========================================================================

TCA Report TCA Report TCA Report TCA Report TCA Report

Address Bin BER CV-P/F ES-P/F SES-P/F UAS-P/F

===========================================================================

sts1-1e-1-1 QH Enable Enable Disable Disable Disable
