Filter Panel 6
The filter panel (Figure 6-5 and Figure 6-6) is a factory-installed unit mounted next
to the right-hand flange on the Low Speed Shelf - Complementary, High Speed
Shelf, Enhanced High Speed Shelf, and the Condensed High Speed Shelf. The
filter panel has −48 V power filters, an electrostatic discharge jack, and a green
PWRONLED.ThePWRONLEDshowsthattheshelfisreceiving−48 V power.
Figure 6-5. Filter Panel for the Enhanced High Speed Shelf
PWR
ON
ESD WRIST
STRAP GROUND
Identification
Label
Line
-48 V Power On
